Introduction

The rapid development of electronic technology has led to the creation of various equipment used in households, offices, and industries. Most of these equipment require a power supply in the form of direct current (DC), while the available source is generally alternating current (AC). To overcome this problem, a device called a rectifier is needed that functions to convert the AC current into DC current. However, the use of rectifier can cause distortion in the form of current waves known as harmonics. This harmonics can interfere with the performance of other electrical equipment that is connected to the same resources. Therefore, it is essential to reduce the harmonics produced by the rectifier to remain below the permitted standards.

The Problem of Harmonics

Harmonics are a type of distortion that occurs in the current wave when a rectifier is used to convert AC current into DC current. These harmonics can cause problems in the performance of other electrical equipment that is connected to the same resources. The harmonics can also cause electrical pollution, which is increasingly important in the current era of sustainability. Therefore, it is crucial to reduce the harmonics produced by the rectifier to meet the established standards.

Methods for Reducing Harmonics

Many methods have been developed to reduce the harmonics produced by rectifiers. One effective method is the use of an inductor filter on the input side of the rectifier. By using this filter, we can reduce the harmonic current produced. For example, in a rectifier that has a resistive load of 125Ω with a grant capacitor of 204 µF, a third harmonic current is produced by 3.62 ampertites. However, when the inductor filter with a value of 159 mh is installed, the third harmonic current can be reduced to 0.59 amper. According to the IEC-1000-3-2 standards, the third permissible harmonic current is 2.3 amper, so that with the application of this inductor filter, the resulting harmonic current meets the established standards.

Benefits of Using an Inductor Filter

The use of an inductor filter in the bleeding system not only provides benefits in reducing harmonics, but also increases the operational efficiency of equipment. By reducing harmonics, we can reduce the risk of damage to other connected electronic components, extend the life of the equipment, and reduce maintenance costs. In addition, in the environmental context, reducing harmonics also contributes to reducing electrical pollution, which is increasingly important in the current era of sustainability.

Designing an Inductor Filter

However, keep in mind that in implementing an inductor filter, there are several factors that must be considered, such as the size and value of inductance in accordance with the load and characteristics of the system used. Inappropriate filter design can cause side effects such as decreased efficiency or even damage to other components. Therefore, careful analysis and the selection of appropriate components are needed to achieve optimal results.

Conclusion

In conclusion, the application of filter inductors to one phase rectifier has proven to be effective in reducing harmonics and complying with established standards. By continuing to conduct research and development in this technology, we can optimize the performance of existing electronic systems and support the use of cleaner and more efficient energy.
